TM 5-3805-294-23-1
0129
Table 1. Glow Plug Check - Continued.
Test or Inspection
Corrective Action
Malfunction
7.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
8.
Under ECU - Data List - All,
select Fuel Temperature.
(Volume 3, WP 0363)
9.
Monitor Fuel Temperature
data point in Service
ADVISOR.
10.
When finished monitoring,
select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
11.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
12.
Turn key switch to OFF
1.
If data point indicates actual
position (TM 5-3805-294-10).
fuel temperature within 9F
(5C), proceed to Malfunction
(Volume 5, WP 0794)
23.
2.
If data point does not indicate
actual fuel temperature within
9F (5C), it is possible that
another fault exists or that
another troubleshooting
procedure applies. If this was
the first time through this
procedure, restart procedure
at Malfunction 1.
END OF WORK PACKAGE
