TM 5-3805-294-23-1
0137
Table 1. DTC 13311.04 - Fuel Level Sensor Open Circuit - Continued.
Test or Inspection
Corrective Action
Malfunction
Measure resistance (Volume
1.
If continuity is not present,
10.
Open Circuit
replace monitor controller
Between Connector
3, WP 0369) between
wiring harness. (Volume 4,
X21 Socket 2 and
connector X21 socket 2
Connector X24 Pin
WP 0519) Restore machine to
(Volume 5, WP 0800, Figure
3.
original condition.
88) and connector X24 pin 3.
(Volume 5, WP 0800, Figure
2.
If continuity is present, replace
91) Note reading.
cab wiring harness. (Volume 4,
WP 0504) Restore machine to
original condition.
END OF WORK PACKAGE
0137-5/6 blank
