TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 13311.04 - FUEL LEVEL SENSOR OPEN CIRCUIT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0342
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0362
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0369
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0478
Multimeter, Digital
Volume 4, WP 0504
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0516
Probe Set, Standard
Volume 4, WP 0518
(Volume 5, WP 0796, Table 2, Item 91)
Volume 4, WP 0519
Test Set, MSD Electronic Systems
Volume 4, WP 0566
(Volume 5, WP 0796, Table 2, Item 116)
Volume 4, WP 0589
Volume 5, WP 0800
Materials/Parts
Wire, Jumper
Equipment Condition
(Volume 5, WP 0792)
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
Personnel Required
ADVISOR. (Volume 3, WP 0375)
Construction Equipment Repairer 91L (2)
References
Volume 3, WP 0312
Related Information
Fuel level sensor open circuit.
TROUBLESHOOTING PROCEDURE
Table 1. DTC 13311.04 - Fuel Level Sensor Open Circuit.
Malfunction
Test or Inspection
Corrective Action
1.
Remove center top cover.
1.
Connector B18 Has
Damage or Loose
(Volume 4, WP 0589)
Sockets.
2.
Disconnect connector B18
from fuel level sensor. (Volume
5, WP 0800, Figure 13)
0137-1
