TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 13311.03 - FUEL LEVEL SENSOR SHORT CIRCUIT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0369
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0478
(Volume 5, WP 0796, Table 2, Item 2)
Volume 4, WP 0504
Multimeter, Digital
Volume 4, WP 0516
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0518
Probe Set, Standard
Volume 4, WP 0519
(Volume 5, WP 0796, Table 2, Item 91)
Volume 4, WP 0566
Test Set, MSD Electronic Systems
Volume 4, WP 0589
(Volume 5, WP 0796, Table 2, Item 116)
Volume 5, WP 0800
Personnel Required
Equipment Condition
Construction Equipment Repairer 91L (1)
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
References
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0312
Volume 3, WP 0342
Related Information
Fuel level sensor shorted to ground.
TROUBLESHOOTING PROCEDURE
Table 1. DTC 13311.03 - Fuel Level Sensor Short Circuit.
Malfunction
Test or Inspection
Corrective Action
1.
Remove center top cover.
1.
Connector B18 Has
Damage or Loose
(Volume 4, WP 0589)
Sockets.
2.
Disconnect connector B18
from fuel level sensor. (Volume
5, WP 0800, Figure 13)
0136-1
