TM 5-3805-294-23-1
0136
Table 1. DTC 13311.03 - Fuel Level Sensor Short Circuit - Continued.
Test or Inspection
Corrective Action
Malfunction
Measure resistance (Volume
1.
If continuity is present, replace
10.
Shorted Circuit
monitor controller wiring
Between Connector
3, WP 0369) between
harness. (Volume 4,
X24 Pin 3 and
connector X24 pin 3 (Volume
Ground.
WP 0519) Restore machine to
5, WP 0800, Figure 91) and
original condition. Clear and
known good ground. Note
refresh DTCs. (Volume 3,
reading.
WP 0362)
2.
If continuity is not present,
replace cab wiring harness.
(Volume 4, WP 0504) Restore
machine to original condition.
Clear and refresh DTCs.
(Volume 3, WP 0362)
END OF WORK PACKAGE
