TM 5-3805-294-23-4
0549
REMOVAL - Continued
2
7
6
HYEX02471
Figure 3. Servo Motor Removal.
END OF TASK
INSTALLATION
1.
Install servo motor (Figure 4, Item 2) to air conditioner/heater unit (Figure 4, Item 7) with three screws (Figure
4, Item 6).
