TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB HANDRAILS REPLACEMENT
INITIAL SETUP:
Equipment Condition
Tools and Special Tools
Machine safely parked and shut down
Tool Kit, General Mechanic's: Automotive (Volume
(TM 5-3805-294-10). (Volume 5, WP 0794)
5, WP 0796, Table 2, Item 119)
Left rear view mirror removed. (WP 0613)
Materials/Parts
Lockwasher (Volume 5, WP 0798, Table 1, Item
Time to Complete
0.7 Hour(s)
17) Qty: 2
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 101 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
1.
Remove two bolts (Figure 1, Item 1), lockwashers (Figure 1, Item 2), washers (Figure 1, Item 3), and forward
handrail (Figure 1, Item 4) from operator cab frame (Figure 1, Item 5). Discard lockwashers.
0559-1
