TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB INTERIOR LAMP REPLACEMENT
INITIAL SETUP:
Equipment Condition
Tools and Special Tools
Machine safely parked and shut down
Tool Kit, General Mechanic's: Automotive
(TM 5-3805-294-10). (Volume 5, WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
Negative battery cable disconnected. (WP 0521)
Materials/Parts
Lamp, Incandescent
Time to Complete
(Volume 5, WP 0798, Table 1, Item 48)
0.3 Hour(s)
Qty: 1
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 100 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove two screws (Figure 1, Item 1) and dome lamp cover (Figure 1, Item 2) from cab wall (Figure 1, Item
3).
0562-1
