TM 5-3805-294-23-4
0562
REMOVAL - Continued
6
4
2
3
5
7
1
HYEX01673
Figure 1. Cab Interior Lamp Removal.
2.
Spread ground terminal (Figure 1, Item 4) and power terminal (Figure 1, Item 5) and remove dome lamp (Figure
1, Item 6) from hanger (Figure 1, Item 7).
END OF TASK
INSTALLATION
1.
Spread ground terminal (Figure 2, Item 4) and power terminal (Figure 2, Item 5) and install dome lamp (Figure
2, Item 6) to hanger (Figure 2, Item 7).
