TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB HEATER CORE TEMPERATURE SENSOR REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Cab rear tray and cover removed. (WP 0566)
Personnel Required
Time to Complete
Construction Equipment Repairer 91L (1)
2.0 Hour(s)
References
TM 5-3805-294-24P: Fig. 122 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove right-hand console wiring harness W11 connector B43 (Figure 1, Item 1) from heater core temperature
sensor (Figure 1, Item 2).
0561-1
