TM 5-3805-294-23-4
0560
INSTALLATION - Continued
4
3
5
HYEX01923
Figure 11. Bolt Installation.
NOTE
Step (7) is only required for operation during cold weather. Valves may be left closed during
warm weather operation to aid in air conditioning efficiency.
7.
Turn valve (Figure 12, Item 1) and valve (Figure 12, Item 2) counterclockwise 1/4 turn to open.
