TM 5-3805-294-23-4
0591
REMOVAL - Continued
2.
Remove cover (Figure 1, Item 3) from machine (Figure 1, Item 4).
END OF TASK
INSTALLATION
1.
Position cover (Figure 2, Item 3) on machine (Figure 2, Item 4).
4
3
2
1
HYEX00349
Figure 2.
Cooling Compartment Lower Access Cover Installation.
2.
Install six screws (Figure 2, Item 1) and washers (Figure 2, Item 2) to cover (Figure 2, Item 3) and machine
(Figure 2, Item 4).
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
