TM 5-3805-294-23-4
0594
ENGINE COVER INSTALLATION - Continued
3
4
6
7
5
HYEX02162
Figure 9.
Connect Cover Rod End.
5.
Remove lifting device (Figure 10, Item 2) from engine cover (Figure 10, Item 1).
2
1
HYEX02161
Figure 10.
Remove lifting Device.
6.
If the HYEX is equipped with a Supplemental Armor System Cab, then install CCTV Conduit. (Volume 5,
WP 0794)
END OF TASK
