TM 5-3805-294-23-4
FIELD MAINTENANCE
RIGHT SIDE HANDRAIL REPLACEMENT
INITIAL SETUP:
Equipment Condition
Tools and Special Tools
Machine safely parked and shut down
Tool Kit, General Mechanic's: Automotive (Volume
(TM 5-3805-294-10). (Volume 5, WP 0794)
5, WP 0796, Table 2, Item 119)
Right rear view mirror removed. (WP 0602)
Materials/Parts
Sealing Compound, Thread Lock
Time to Complete
(Volume 5, WP 0797, Table 1, Item 43)
0.5 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 139 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
1.
Remove two screws (Figure 1, Item 1) and washers (Figure 1, Item 2) from handrail (Figure 1, Item 3) and
frame (Figure 1, Item 4).
0603-1
