TM 5-3805-294-23-4
0602
REMOVAL - Continued
6
7
8
9
10
HYEX00623
Figure 2. Right Rear View Mirror Removal.
END OF TASK
INSTALLATION
1.
Install mirror (Figure 3, Item 9) to holder (Figure 3, Item 10) with screw (Figure 3, Item 6), lockwasher (Figure
3, Item 7), and nut (Figure 3, Item 8).
