TM 5-3805-294-23-4
0603
REMOVAL - Continued
5
3
6
3
7
1
2
3
4
HYEX00568
8
Figure 1. Right Side Handrail Removal.
2.
Remove two screws (Figure 1, Item 5), washers (Figure 1, Item 6), and handrail (Figure 1, Item 3) from fuel
tank (Figure 1, Item 7) and grommet (Figure 1, Item 8).
3.
Remove grommet (Figure 1, Item 8) from frame (Figure 1, Item 4).
END OF TASK
INSTALLATION
WARNING
ADHESIVES AND SEALANTS
1.
Install grommet (Figure 2, Item 8) to frame (Figure 2, Item 4).
