TM 5-3805-294-23-4
0631
REMOVAL - Continued
9.
Remove three bolts (Figure 1, Item 8), cushion clips (Figure 1, Item 9), hose (Figure 1, Item 1), and hose
(Figure 1, Item 3) from machine (Figure 1, Item 10).
END OF TASK
INSTALLATION
WARNING
NOTE
Install tie wraps as required.
1.
Install hose (Figure 2, Item 1) and hose (Figure 2, Item 3) to machine (Figure 2, Item 10) with three bolts (Figure
2, Item 8) and cushion clips (Figure 2, Item 9).
0631-4
