INSTALLATION - Continued
Figure 1. Hoses and Fittings Removal.

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  1020    1021    1022    1023    1024  1025  1026    1027    1028    1029    1030
. .
TM 5-3805-294-23-4
0632
FIELD MAINTENANCE
AUXILIARY CIRCUIT ARM LINES REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
O-ring (Volume 5, WP 0798, Table 1, Item 225)
(Volume 5, WP 0796, Table 2, Item 119)
Qty: 7
Cap and Plug Set (Volume 5, WP 0796, Table 2,
O-ring (Volume 5, WP 0798, Table 1, Item 179)
Item 55)
Qty: 2
Gloves, Rubber (Volume 5, WP 0796, Table 2,
Item 55)
Personnel Required
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Construction Equipment Repairer 91L (1)
Item 58)
Pan, Drain (Volume 5, WP 0796, Table 2, Item
55)
References
TM 5-3805-294-24P: Fig. 209, Fig. 210 (Volume 5,
WP 0794)
Materials/Parts
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Lubricating Oil, Engine OE/HDO 15W-40
WP 0794)
(Volume 5, WP 0797, Table 1, Item 18)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Equipment Condition
Tags (Volume 5, WP 0797, Table 1, Item 52)
Machine safely parked and shut down
Tie Wraps (Volume 5, WP 0797, Table 1, Item
(TM 5-3805-294-10). (Volume 5, WP 0794)
56)
Hydraulic system pressure relieved. (Volume 5,
WP 0767)
Auxiliary circuit quick disconnect fittings removed.
(WP 0636)
Time to Complete
1.0 Hour(s)
RIGHT SIDE AUXILIARY CIRCUIT ARM LINES REMOVAL
WARNING
LUBRICATING OIL
0632-1
