TM 5-3805-294-23-4
FIELD MAINTENANCE
AUXILIARY CIRCUIT QUICK DISCONNECT FITTINGS REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
O-ring (Volume 5, WP 0798, Table 1, Item 228)
(Volume 5, WP 0796, Table 2, Item 119)
Qty: 2
Cap and Plug Set (Volume 5, WP 0796, Table 2,
O-ring (Volume 5, WP 0798, Table 1, Item 179)
Item 55)
Qty: 1
Gloves, Rubber (Volume 5, WP 0796, Table 2,
Item 55)
Personnel Required
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Construction Equipment Repairer 91L (1)
Item 58)
Pan, Drain (Volume 5, WP 0796, Table 2, Item
55)
References
Wrench, Adjustable, Auto Locking 18 in.
TM 5-3805-294-24P: Fig. 209, Fig. 210 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 55)
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Lubricating Oil, Engine OE/HDO 15W-40
(Volume 5, WP 0797, Table 1, Item 18)
Equipment Condition
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
Machine safely parked and shut down
34)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Tags (Volume 5, WP 0797, Table 1, Item 52)
Hydraulic system pressure relieved. (Volume 5,
O-ring (Volume 5, WP 0798, Table 1, Item 209)
WP 0767)
Qty: 3
Time to Complete
0.5 Hour(s)
REMOVAL
WARNING
WARNING
Hydraulic system operates at high pressures and temperatures. Always allow hydraulic oil to
cool and relieve pressure in hydraulic reservoir before working on hydraulic system. Wear
eye protection and gloves to prevent injury. Open lines and hoses slowly and wait for any
0636-1
