TM 5-3805-294-23-4
FIELD MAINTENANCE
AUXILIARY CIRCUIT BOOM RETURN LINES REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
O-ring (Volume 5, WP 0798, Table 1, Item 228)
(Volume 5, WP 0796, Table 2, Item 119)
Qty: 1
Cap and Plug Set (Volume 5, WP 0796, Table 2,
O-ring (Volume 5, WP 0798, Table 1, Item 236)
Item 55)
Qty: 1
Pan, Drain (Volume 5, WP 0796, Table 2, Item
55)
Personnel Required
Wrench, Adjustable, 18 in.
Construction Equipment Repairer 91L (1)
(Volume 5, WP 0796, Table 2, Item 55)
Wrench, Combination, 1 5/8 in.
(Volume 5, WP 0796, Table 2, Item 55)
References
TM 5-3805-294-24P: Fig. 205, Fig. 207 (Volume 5,
WP 0794)
Materials/Parts
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Lubricating Oil, Engine OE/HDO 15W-40
WP 0794)
(Volume 5, WP 0797, Table 1, Item 18)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Equipment Condition
Tags (Volume 5, WP 0797, Table 1, Item 52)
Machine safely parked and shut down
O-ring (Volume 5, WP 0798, Table 1, Item 225)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Qty: 4
Negative battery cable disconnected. (WP 0521)
Hydraulic system pressure relieved. (Volume 5,
WP 0767)
Vacuum applied to hydraulic reservoir. (WP 0620)
Time to Complete
1.1 Hour(s)
LOWER LINE REMOVAL
WARNING
0637-1
