Figure 2. Hose Installation.
BOOM LUBRICATION SYSTEM REPLACEMENT

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  1138    1139    1140    1141    1142  1143  1144    1145    1146    1147    1148
. .
TM 5-3805-294-23-4
0650
INSTALLATION - Continued
2.
Install hose (Figure 2, Item 22) and O-ring (Figure 2, Item 25) to fitting (Figure 2, Item 26).
3.
Lightly lubricate O-ring (Figure 2, Item 23) with clean oil.
4.
Install hose (Figure 2, Item 22) and O-ring (Figure 2, Item 23) to fitting (Figure 2, Item 24).
5.
Install hose (Figure 2, Item 13) to fitting (Figure 2, Item 21).
6.
Install hose (Figure 2, Item 9) to fitting (Figure 2, Item 20).
7.
Install hose (Figure 2, Item 15) to fitting (Figure 2, Item 19).
8.
Install hose (Figure 2, Item 7) to fitting (Figure 2, Item 18).
9.
Install hose (Figure 2, Item 11) to fitting (Figure 2, Item 17).
10.
Install hose (Figure 2, Item 15) to fitting (Figure 2, Item 16).
11.
Install hose (Figure 2, Item 13) to fitting (Figure 2, Item 14).
12.
Install hose (Figure 2, Item 11) to fitting (Figure 2, Item 12).
13.
Install hose (Figure 2, Item 9) to fitting (Figure 2, Item 10).
14.
Install hose (Figure 2, Item 7) to fitting (Figure 2, Item 8).
15.
Install hose (Figure 2, Item 3) to fitting (Figure 2, Item 6).
16.
Install hose (Figure 2, Item 1) to fitting (Figure 2, Item 5).
17.
Install hose (Figure 2, Item 3) to fitting (Figure 2, Item 4).
18.
Install hose (Figure 2, Item 1) to fitting (Figure 2, Item 2).
END OF TASK
FOLLOW-ON MAINTENANCE
1.
Install cab rear lower armor plate. (WP 0588)
2.
Install center top cover. (WP 0589)
3.
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0650-6
