TM 5-3805-294-23-1
0022
Table 1. DTC 100.04 - Engine Oil Pressure Signal Out Of Range Low - Continued.
Test or Inspection
Corrective Action
Malfunction
2.
Measure resistance (Volume
1.
If any measurement was less
than 100 kohms, replace
3, WP 0369) between engine
engine wiring harness
wiring harness connector J03
socket C3 (Volume 5,
(Volume 4, WP 0510) and
replace engine interface wiring
WP 0800, Figure 48) and all
harness. (Volume 4,
other sockets on engine
interface wiring harness
WP 0509) Restore machine to
connector J02. (Volume 5,
original condition and perform
Harness Diagnostic Mode
WP 0800, Figure 47)
Note readings.
Test. (Volume 3, WP 0345)
2.
If all measurements were
greater than 100 kohms,
proceed to Malfunction 17.
1.
Reconnect all connectors.
17.
Check DTC 100.04
For Active Status.
2.
Turn the key switch to the ON
position, but DO NOT START
ENGINE (TM 5-3805-294-10).
(Volume 5, WP 0794)
3.
Refresh DTCs. Note if DTC
100.04 is still an active DTC.
(Volume 3, WP 0362)
4.
Turn the key switch to the OFF
1.
If DTC 100.04 is still an active
position (TM 5-3805-294-10).
DTC, problem was not found
and may have been missed
(Volume 5, WP 0794)
during troubleshooting.
Restart procedure at
Malfunction 1.
2.
If DTC 100.04 is not an active
DTC, problem corrected.
END OF WORK PACKAGE
0022-10
