TM 5-3805-294-23-1
0022
Table 1. DTC 100.04 - Engine Oil Pressure Signal Out Of Range Low - Continued.
Test or Inspection
Corrective Action
Malfunction
5.
Turn the key switch to the OFF
1.
If DTC 100.04 is still active, it is
position (TM 5-3805-294-10).
possible that another fault
exists or that another
(Volume 5, WP 0794)
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
2.
If DTC 100.04 is not active,
problem corrected. Restore
machine to original condition
and perform Harness
Diagnostic Mode Test.
(Volume 3, WP 0345)
1.
Turn the key switch to the ON
9.
Check for DTC
position, but DO NOT START
3510.04.
ENGINE (TM 5-3805-294-10).
(Volume 5, WP 0794)
2.
Refresh DTCs. Note if DTC
3510.04 is an active DTC.
(Volume 3, WP 0362)
3.
Turn the key switch to the OFF
1.
If DTC 3510.04 is an active
position (TM 5-3805-294-10).
DTC, discontinue this
troubleshooting procedure.
(Volume 5, WP 0794)
Restore machine to original
condition and perform the
troubleshooting procedure for
DTC 3510.04. (WP 0108)
2.
If DTC 3510.04 is not an active
DTC, proceed to Malfunction
10.
1.
Disconnect engine wiring
10.
Engine Wiring
harness connector J03.
Harness Connector
J03 Has Damage or
(Volume 5, WP 0800, Figure
Loose Sockets.
48)
2.
Inspect sockets H3, H4, and
1.
If damaged or has loose
C3 on engine wiring harness
sockets, replace engine wiring
connector J03 for damage and
harness. (Volume 4,
loose sockets.
WP 0510) Restore machine to
original condition and perform
Harness Diagnostic Mode
Test. (Volume 3, WP 0345)
2.
If not damaged and does not
have loose sockets, proceed to
Malfunction 11.
0022-7
