TM 5-3805-294-23-1
0022
Table 1. DTC 100.04 - Engine Oil Pressure Signal Out Of Range Low - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Turn key switch to ON position,
4.
Sensor Supply
but DO NOT START ENGINE
Voltage Below 5.5
(TM 5-3805-294-10). (Volume
Volts.
5, WP 0794)
2.
Measure voltage (Volume 3,
WP 0369) between sockets A
and B on engine wiring
harness connector P04.
(Volume 5, WP 0800, Figure
56) Note reading.
3.
Turn key switch to OFF
1.
If between 4.5 - 5.5 volts,
position (TM 5-3805-294-10).
proceed to Malfunction 5.
(Volume 5, WP 0794)
2.
If less than 4.5 volts, proceed
to Malfunction 9.
3.
If greater than 5.5 volts,
reconnect all connectors and
discontinue this
troubleshooting procedure.
Perform the troubleshooting
procedure for DTC 3510.03 as
though the DTC is active.
1.
Verify the key switch is in the
5.
Engine Oil Pressure
OFF position (TM
Input Voltage is
5-3805-294-10). (Volume 5,
Greater Than 4.8
Volts.
WP 0794)
2.
Install a jumper wire between
engine wiring harness
connector P04 sockets B and
C. (Volume 5, WP 0800,
Figure 56)
3.
Turn the key switch to the ON
position, but DO NOT START
ENGINE (TM 5-3805-294-10).
(Volume 5, WP 0794)
4.
Select Readings and select
Connect to Model(s). (Volume
3, WP 0363)
5.
Select Dearborn Protocol
Adapter (DPA 4+) USB for the
Readings Adapter, and select
OK. (Volume 3, WP 0363)
0022-3
