TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 100.04 - ENGINE OIL PRESSURE SIGNAL OUT OF RANGE LOW
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
(Volume 5, WP 0796, Table 2, Item 119)
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0345
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0362
Multimeter, Digital
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 77)
Volume 3, WP 0369
Probe Set, Standard
Volume 3, WP 0417
(Volume 5, WP 0796, Table 2, Item 91)
Volume 4, WP 0509
Test Set, MSD Electronic Systems
Volume 4, WP 0510
(Volume 5, WP 0796, Table 2, Item 116)
Volume 4, WP 0511
Volume 4, WP 0593
Volume 5, WP 0800
Materials/Parts
Wire, Jumper
(Volume 5, WP 0792)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Test Equipment Setup for MSD and Service
Construction Equipment Repairer 91L (2)
ADVISOR. (Volume 3, WP 0375)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
DTC 100.04
When DTC is Displayed
When the ignition is ON and the error is active.
Related Information
The engine oil pressure input voltage drops below the sensor's low voltage specification. The voltage corresponds
to a pressure that is lower than what is physically possible for engine oil pressure.
Alarm Level
Warning.
Control Unit Response
The ECU will try to maintain the engine operating envelope.
0022-1
