TM 5-3805-294-23-1
0021
Table 1. DTC 100.01 - Engine Oil Pressure Signal Extremely Low - Continued.
Test or Inspection
Corrective Action
Malfunction
6.
Clear and refresh the DTCs.
Many new DTCs will be active.
Only note if DTC 100.04 is an
active DTC. (Volume 3,
WP 0362)
7.
Turn the key switch to the OFF
1.
If DTC 100.04 is an active
position (TM 5-3805-294-10).
DTC, proceed to Malfunction
8.
(Volume 5, WP 0794)
2.
If DTC 100.04 is not an active
DTC, replace ECU. (Volume 4,
WP 0508) Restore machine to
original condition and operate
engine through normal speed
and load (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
Inspect engine wiring harness
1.
If damaged or has loose
8.
Engine Wiring
connector J03 for damage and
sockets, replace engine wiring
Harness Connector
loose sockets.
harness. (Volume 4,
J03 Has Damage or
Loose Sockets.
WP 0510) Restore machine to
original condition and operate
engine through normal speed
and load (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If not damaged and does not
have loose sockets, problem
was not found and may have
been missed during
troubleshooting. Restore
machine to original condition
and restart procedure at
Malfunction 1.
END OF WORK PACKAGE
