TM 5-3805-294-23-1
0048
Table 1. DTC 611.04 - Injector Shorted to Voltage Source - Continued.
Test or Inspection
Corrective Action
Malfunction
10.
Under Connected Data Points,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0363)
11.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
12.
Under ECU - Data List - All,
select Fuel Rail Pressure -
Actual. (Volume 3, WP 0363)
13.
Monitor Fuel Rail Pressure.
Pressure should be below 725
psi (5 MPa).
14.
Perform Harness Diagnostic
Mode Test. (Volume 3,
WP 0345)
15.
Refresh DTCs. Note if DTC
611.04 is an active DTC.
(Volume 3, WP 0362)
16.
Select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
17.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
18.
Turn key switch to OFF
1.
If DTC 611.04 is not an active
position (TM 5-3805-294-10).
DTC, problem corrected.
Restore machine to original
(Volume 5, WP 0794)
condition.
2.
If DTC 611.04 is an active
DTC, it is possible that another
fault exists or that another
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
END OF WORK PACKAGE
0048-10
