TM 5-3805-294-23-1
0048
Table 1. DTC 611.04 - Injector Shorted to Voltage Source - Continued.
Test or Inspection
Corrective Action
Malfunction
Measure resistance (Volume
1.
If less than 1 kohms, replace
17.
Short Circuit
engine wiring harness.
Between Engine
3, WP 0369) between engine
Wiring Harness
wiring harness connector J01
(Volume 4, WP 0510) Restore
Connector J01
socket G1 (Volume 5,
machine to original condition
Socket G1 and
and perform Harness
WP 0800, Figure 46) and a
Ground.
Diagnostic Mode Test.
known good ground. Note
reading.
(Volume 3, WP 0345)
2.
If greater than 1 kohms,
proceed to Malfunction 18.
Measure resistance (Volume
1.
If less than 1 kohms, replace
18.
Short Circuit
engine wiring harness.
Between Engine
3, WP 0369) between engine
Wiring Harness
wiring harness connector J01
(Volume 4, WP 0510) Restore
Connector J01
socket G2 (Volume 5,
machine to original condition
Socket G2 and
and perform Harness
WP 0800, Figure 46) and a
Ground.
Diagnostic Mode Test.
known good ground. Note
reading.
(Volume 3, WP 0345)
2.
If greater than 1 kohms,
proceed to Malfunction 19.
Measure resistance (Volume
1.
If less than 1 kohms, replace
19.
Short Circuit
engine wiring harness.
Between Engine
3, WP 0369) between engine
Wiring Harness
wiring harness connector J01
(Volume 4, WP 0510) Restore
Connector J01
socket G1 and all other
machine to original condition
Socket G1 and All
sockets on engine wiring
and perform Harness
Other Sockets on
harness connector J01
Diagnostic Mode Test.
Engine Wiring
(Volume 5, WP 0800, Figure
(Volume 3, WP 0345)
Harness Connector
46) EXCEPT the following
2.
If greater than 1 kohms,
J01.
sockets:
proceed to Malfunction 20.
Socket A1.
Socket B1.
Socket C1.
Socket D1.
Socket E1.
Socket F1.
0048-8
