Table 1. Engine Does Not Develop Full Power - Continued.
Test or Inspection
Corrective Action
Malfunction
2.
Visually inspect connectors
1.
If damaged or has loose
sockets, replace cab wiring
X30 (Volume 5, WP 0800,
harness. (Volume 4,
Figure 96) and X31 (Volume 5,
WP 0504)Restore machine to
WP 0800, Figure 97) for
original condition and operate
damage and loose sockets.
engine through normal speed
and load. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If not damaged and does not
have loose sockets, replace
main controller. (Volume 4,
WP 0517)Restore machine to
original condition and operate
engine through normal speed
and load. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
1.
Perform Charge Air System
17.
Charge Air System
Faulty.
(WP 0112) test.
2.
Operate engine to where fault
1.
If engine performance is
occurred. (TM 5-3805-294-10)
restored, problem corrected.
(Volume 5, WP 0794) Note
2.
If engine performance is not
engine performance.
restored, proceed to
Malfunction 18.
Perform Low-Pressure Fuel
1.
If test failed, repair faults found
18.
Low-Pressure Fuel
Supply System Test.
in Low-Pressure Fuel Supply
Supply System
Test.
System Test. (WP 0131)
Restore machine to original
condition and operate engine
through various rpm ranges.
(TM 5-3805-294-10) (Volume
5, WP 0794)Clear and refresh
DTCs. (Volume 3, WP 0362)
2.
If test passed, proceed to
Malfunction 19.
