TM 5-3805-294-23-1
0116
Table 1. Engine Does Not Develop Full Power - Continued.
Test or Inspection
Corrective Action
Malfunction
Visually inspect exhaust pipes
1.
If restricted, remove debris or
28.
Exhaust Pipes and
and muffler for damage or
foreign objects.
Muffler Damaged or
restrictions. (Volume 3,
Restricted.
2.
If damaged, replace exhaust
WP 0482)
pipes/muffler. (Volume 3,
WP 0482) Restore machine to
original condition and operate
engine through various rpm
ranges. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
3.
If not restricted or damaged,
proceed to Malfunction 29.
Perform Engine Intake and
1.
If engine performance is
29.
Intake and Exhaust
Exhaust Valve Adjustment.
restored, problem corrected.
Valves Out of
Adjustment.
(Volume 3, WP 0414)
2.
If engine performance is not
restored, proceed to
Malfunction 30.
1.
Turn key switch to ON position,
30.
Check Engine Load.
START ENGINE. (TM
5-3805-294-10) (Volume 5,
WP 0794)
2.
Select Readings and select
Connect to Model(s). (Volume
3, WP 0363)
3.
Select Dearborn Protocol
Adapter (DPA 4+) USB for the
Readings Adapter, and select
OK. (Volume 3, WP 0363)
4.
Select Engine Control Unit
(ECU) Only. (Volume 3,
WP 0363)
5.
Under Connected Data Points,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0363)
6.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
0116-13
