TM 5-3805-294-23-1
0116
Table 1. Engine Does Not Develop Full Power - Continued.
Test or Inspection
Corrective Action
Malfunction
Perform Cylinder
1.
If test is within limits, proceed
9.
Mechanical Gauge
Compression Test With
to Malfunction 10.
Compression Test.
Gauge. (Volume 3, WP 0328)
2.
If pressure is too low, replace
Note readings.
cylinder head. (Volume 3,
WP 0407) Restore machine to
original condition and operate
engine through various rpm
ranges. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
3.
If pressure is too high, replace
engine. (Volume 3, WP 0410)
Restore machine to original
condition and operate engine
through various rpm ranges.
(TM 5-3805-294-10) (Volume
5, WP 0794)Clear and refresh
DTCs. (Volume 3, WP 0362)
Perform turbocharger
1.
If damaged or faulty, replace
10.
Turbocharger is
inspection. (Volume 3,
turbocharger. (Volume 3,
Damaged or Faulty.
WP 0382)
WP 0452) Restore machine to
original condition and operate
engine through various rpm
ranges. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If not damaged and not faulty,
replace engine. (Volume 3,
WP 0410) Restore machine to
original condition and operate
engine through various rpm
ranges. (TM 5-3805-294-10)
(Volume 5, WP 0794)Clear
and refresh DTCs. (Volume 3,
WP 0362)
Operate engine through
1.
If engine misfires or runs
11.
Engine Misfires or
various rpm ranges. (TM
irregularly, discontinue this
Runs Irregularly.
5-3805-294-10) (Volume 5,
troubleshooting procedure and
perform procedure for Engine
WP 0794) Note if engine
Misfires - Runs Irregularly.
misfires or runs irregularly.
2.
If engine does not misfire or
run irregularly, proceed to
Malfunction 12.
0116-5
