Table 1. Engine Cranks/Will Not Start - Continued.
Test or Inspection
Corrective Action
Malfunction
2.
Check intake and exhaust
1.
If valves are out of adjustment,
valve lash. (Volume 3,
adjust valves. (Volume 3,
WP 0414)
WP 0414) Restore machine to
original condition.
2.
If valves are not out of
adjustment, proceed to
Malfunction 19.
1.
Remove and disassemble
19.
Rocker Arms or
rocker arm shaft assembly.
Shaft Damaged or
Worn.
(Volume 3, WP 0444)
2.
Visually inspect rocker arms,
1.
If any components are
springs, and shaft for wear,
damaged or worn, replace
scoring, grooves, and
damaged or worn components
damage.
as needed. (Volume 3,
WP 0444) Restore machine to
original condition.
2.
If no components are
damaged or worn, proceed to
Malfunction 20.
1.
Assemble and install rocker
20.
Replace ECU.
arm shaft assembly. (Volume
3, WP 0444)
2.
Install valve cover. (Volume 3,
WP 0453)
3.
Replace ECU. (Volume 4,
WP 0508)
4.
Attempt to start engine. (TM
1.
If engine starts, problem
5-3805-294-10) (Volume 5,
corrected.
WP 0794)
2.
If engine does not start, it is
possible that another fault
exists or that another
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
END OF WORK PACKAGE
0115-9/10 blank
