TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 13303.02 - ABNORMAL THERMISTER TEMPERATURE
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 119)
Volume 4, WP 0518
Accessory Kit, MSD Electronic Equipment
(Volume 5, WP 0796, Table 2, Item 2)
Equipment Condition
Test Set, MSD Electronic Systems
Machine safely parked and shut down (TM
(Volume 5, WP 0796, Table 2, Item 116)
5-3805-294-10). (Volume 5, WP 0794)
Thermometer
Test Equipment Setup for MSD and Service
(Volume 5, WP 0796, Table 2, Item 120)
ADVISOR. (Volume 3, WP 0375)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Related Information
Temperature in or around monitor controller is above 185F (85C).
TROUBLESHOOTING PROCEDURE
Table 1. DTC 13303.02 - Abnormal Thermister Temperature.
Test or Inspection
Corrective Action
Malfunction
Using a thermometer, check
1.
If ambient temperature is
1.
Temperature
ambient temperature around
above 185F (85C), proceed
Around Monitor
monitor controller.
to Malfunction 2.
Above 185F (85C).
2.
If ambient temperature is
185F (85C) or lower, replace
monitor controller. (Volume 4,
WP 0518) Restore machine to
original condition. Clear and
refresh DTCs. (Volume 3,
WP 0362)
0132-1
