TM 5-3805-294-23-1
0133
Table 1. DTC 13304.02 - Abnormal Reg Input H Level - Continued
Test or Inspection
Corrective Action
Malfunction
2.
Visually inspect connector X21
1.
If damaged or has loose
for damage or loose sockets.
sockets, replace monitor
controller wiring harness.
(Volume 4, WP 0519) Restore
machine to original condition.
Clear and refresh the DTCs.
(Volume 3, WP 0362)
2.
If not damaged or does not
have loose sockets, proceed to
Malfunction 3.
1.
Start engine (TM
3.
Voltage Below 33.5
5-3805-294-10). (Volume 5,
Vdc at Connector
X21.
WP 0794)
2.
Check voltage between
connector X21 socket 7 and a
known good ground. (Volume
5, WP 0800, Figure 88) Note
reading.
3.
Shut down engine (TM
1.
If voltage is below 33.5 vdc,
5-3805-294-10). (Volume 5,
replace monitor controller.
WP 0794)
(Volume 4, WP 0518) Restore
machine to original condition.
Clear and refresh the DTCs.
(Volume 3, WP 0362)
2.
If voltage is not below 33.5 vdc,
problem was not found and
may have been missed during
troubleshooting. Restart
procedure at Malfunction 1.
END OF WORK PACKAGE
0133-2
