TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 13306.02 - ABNORMAL EXCAVATOR OPERATION AND TESTS (EEPROM)
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 119)
Volume 4, WP 0518
Accessory Kit, MSD Electronic Equipment
(Volume 5, WP 0796, Table 2, Item 2)
Equipment Condition
Test Set, MSD Electronic Systems
Machine safely parked and shut down (TM 5
(Volume 5, WP 0796, Table 2, Item 116)
380529410). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
Personnel Required
ADVISOR. (Volume 3, WP 0375)
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Related Information
Abnormal EEPROM in monitor controller.
TROUBLESHOOTING PROCEDURE
Table 1. DTC 13306.02 - Abnormal Excavator Operation And Tests (EEPROM).
Test or Inspection
Corrective Action
Malfunction
1.
Turn the key switch to the ON
DTC 13306.02 Still
position, but DO NOT START
Active After
ENGINE (TM 5-3805-294-10).
Clearing and
Refreshing DTCs.
(Volume 5, WP 0794)
2.
Clear and refresh DTCs. Note
if DTC 13306.02 is still active.
(Volume 3, WP 0362)
0134-1
