TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 13308.02 - ABNORMAL CAN COMMUNICATION
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive (Volume
Volume 3, WP 0362
5, WP 0796, Table 2, Item 119)
Volume 3, WP 0369
Accessory Kit, MSD Electronic Equipment
Volume 4, WP 0504
(Volume 5, WP 0796, Table 2, Item 2)
Volume 4, WP 0513
Multimeter, Digital
Volume 4, WP 0518
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0519
Probe Set, Standard
Volume 4, WP 0566
(Volume 5, WP 0796, Table 2, Item 91)
Volume 5, WP 0800
Test Set, MSD Electronic Systems
(Volume 5, WP 0796, Table 2, Item 116)
Equipment Condition
Machine safely parked and shut down (TM
Personnel Required
5-3805-294-10). (Volume 5, WP 0794)
Construction Equipment Repairer 91L (2)
Test Equipment Setup for MSD and Service
ADVISOR. (Volume 3, WP 0375)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
TROUBLESHOOTING PROCEDURE
Table 1. DTC 13308.02 - Abnormal CAN Communication.
Test or Inspection
Corrective Action
Malfunction
1.
Turn key switch to ON position,
1.
Check DTC
but DO NOT START ENGINE
13308.02 For Active
(TM 5-3805-294-10). (Volume
Status.
5, WP 0794)
2.
Clear and refresh DTCs. Note
if DTC 13308.02 is still active.
(Volume 3, WP 0362)
3.
Turn key switch to OFF
1.
If DTC 13308.02 is active,
position (TM 5-3805-294-10).
proceed to Malfunction 2.
(Volume 5, WP 0794)
2.
If DTC 13308.02 is not active,
no fault at this time.
1.
Remove cab rear tray.
2.
ICF Has Damage or
Loose Pins.
(Volume 4, WP 0566)
2.
Remove information controller
(ICF). (Volume 4, WP 0513)
0135-1
