TM 5-3805-294-23-4
FIELD MAINTENANCE
WEIGHT SIGN REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition
Tool Kit, General Mechanic's: Automotive
Machine safely parked and shut down
(Volume 5, WP 0796, Table 2, Item 119)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Time to Complete
Construction Equipment Repairer 91L (1)
0.2 Hour(s)
References
TM 5-3805-294-24P: Fig. 72 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
Remove three screws (Figure 1, Item 1) and weight sign (Figure 1, Item 2) from machine (Figure 1, Item 3).
0489-1
