TM 5-3805-294-23-4
FIELD MAINTENANCE
ENGINE OIL SAMPLING VALVE REPLACEMENT
INITIAL SETUP:
Personnel Required
Tools and Special Tools
Construction Equipment Repairer 91L (1)
Tool Kit, General Mechanic's: Automotive
(Volume 5, WP 0796, Table 2, Item 119)
Cap and Plug Set (Volume 5, WP 0796, Table 2,
References
Item 55)
TM 5-3805-294-24P: Fig. 71 (Volume 5,
Pan, Drain (Volume 5, WP 0796, Table 2, Item
WP 0794)
55)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Materials/Parts
Lubricating Oil, Engine OE/HDO 15W-40
Equipment Condition
(Volume 5, WP 0797, Table 1, Item 18)
Machine safely parked and shut down
O-ring (Volume 5, WP 0798, Table 1, Item 31)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Qty: 1
Negative battery cable disconnected. (WP 0521)
O-ring (Volume 5, WP 0798, Table 1, Item 229)
Qty: 1
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
Time to Complete
34)
0.2 Hour(s)
Sealing Compound, Pipe Thread
(Volume 5, WP 0797, Table 1, Item 42)
REMOVAL
WARNING
WARNING
Hydraulic system operates at high pressures and temperatures. Always allow hydraulic oil to
cool and relieve pressure in hydraulic reservoir before working on hydraulic system. Wear
eye protection and gloves to prevent injury. Open lines and hoses slowly and wait for any
residual pressure to relieve before continuing to open lines and hoses. Failure to comply may
result in injury or death to personnel.
