Figure 7. Engine Oil Line Installation.
ENGINE OIL SAMPLING VALVE REPLACEMENT

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  4    5    6    7    8  9  10    11    12    13    14
.
TM 5-3805-294-23-4
0487
INSTALLATION - Continued
3
2
1
HYEX01057
Figure 8.
Engine Oil Filter Installation.
14.
Install oil filter (Figure 8, Item 1) and seal (Figure 8, Item 2) to oil filter head (Figure 8, Item 3).
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0487-8
