TM 5-3805-294-23-4
0487
REMOVAL - Continued
3
7
6
5
4
HYEX01059
Figure 2.
Engine Oil Line Removal.
3.
Remove fitting (Figure 2, Item 6) and O-ring (Figure 2, Item 7) from oil filter head (Figure 2, Item 3). Discard
O-ring.
4.
Remove oil line (Figure 3, Item 8) and O-ring (Figure 3, Item 9) from fitting (Figure 3, Item 10). Discard O-ring.
