TM 5-3805-294-23-4
0498
LIGHT REMOVAL - Continued
4.
Remove two screws (Figure 5, Item 15), washers (Figure 5, Item 16), and mounting bracket (Figure 5, Item 6)
from cab (Figure 5, Item 17).
15
16
6
17
HYEX01816
Figure 5. Mounting Bracket Removal.
END OF TASK
LIGHT INSTALLATION
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Left and right cab front work lights are installed in the same way. Right cab front work
light shown.
Install tie wraps as required.
