TM 5-3805-294-23-4
0498
LIGHT INSTALLATION - Continued
1.
Install mounting bracket (Figure 6, Item 6) to cab (Figure 6, Item 17) with two washers (Figure 6, Item 16) and
screws (Figure 6, Item 15).
15
16
6
17
HYEX01816
Figure 6.
Mounting Bracket Installation.
2.
Install mount (Figure 7, Item 11) to mounting bracket (Figure 7, Item 6) with washer (Figure 7, Item 14) and
screw (Figure 7, Item 13).
12
10
11
6
13
14
HYEX01815
Figure 7. Left and Right Cab Front Work Light Installation.
3.
Install light (Figure 7, Item 12) to mount (Figure 7, Item 11) with two screws (Figure 7, Item 10).
END OF TASK
