TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB FRONT WORK LIGHTS INTERIOR WIRING HARNESS REPLACEMENT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
TM 5-3805-295-13&P (Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
(Volume 5, WP 0796, Table 2, Item 119)
WP 0794)
Materials/Parts
Tags (Volume 5, WP 0797, Table 1, Item 52)
Equipment Condition
Machine safely parked and shut down
Tie Wraps (Volume 5, WP 0797, Table 1, Item
(TM 5-3805-294-10). (Volume 5, WP 0794)
56)
Negative battery cable disconnected. (WP 0521)
Twine (Volume 5, WP 0797, Table 1, Item 58)
Cab rear tray and rear cover removed. (WP 0566)
Qty: 25 ft
Cab headliner removed. (WP 0575)
Personnel Required
Construction Equipment Repairer 91L (1)
Time to Complete
1.1 Hour(s)
References
TM 5-3805-294-24P: Fig. 75, Fig. 76 (Volume 5,
WP 0794)
CONTROL WIRING HARNESS REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
If HYEX is equipped with a Supplemental Armor Set, refer to and use procedure found
in TM 5-3805-295-13&P.
Tag and mark wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
Note position of each tie wrap and remove as required.
1.
Disconnect auxiliary fuse box wiring harness W13 connector X55 (Figure 1, Item 1) from control wiring harness
connector CAB LAMP FRONT (Figure 1, Item 2).
0499-1
