TM 5-3805-294-23-4
0505
INSTALLATION
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Install diodes, connectors, and wiring harnesses as noted prior to removal.
Install tie wraps as noted prior to removal.
Diodes V1 through V8 are installed in the same manner. Diode V3 shown.
Diodes are installed by inserting in cab wiring harness holder and allowing plastic tab on
side of holder to lock diode in.
0505-5
