TM 5-3805-294-23-4
0505
REMOVAL - Continued
2.
Remove diodes V1 (Figure 1, Item 3), V2 (Figure 1, Item 4), V4 (Figure 1, Item 5), and V5 (Figure 1, Item 6)
from cab wiring harness (W1) (Figure 1, Item 2) in the same manner as diode V3 in Step (1).
Table 1.
Diodes V1 Through V8 Identification.
Diode Identification
Component Location
Number
V1
Battery Relay Diode
Connector V1 and Battery Relay Diode. (Volume 5, WP 0800,
Figure 73)
V2
Alternator Excitation Diode
Connector V2 and Alternator Excitation Diode.
(Volume 5, WP 0800, Figure 74)
V3
Load Dump Relay Diode
Connector V3 and Load Dump Relay Diode.
(Volume 5, WP 0800, Figure 75)
V4
Security Diode
Connector V4 and Security Diode. (Volume 5, WP 0800, Figure
76)
V5
Start Relay Diode
Connector V5 and Start Relay Diode. (Volume 5, WP 0800,
Figure 77)
V6
Auxiliary Power Connector Diode Connector V6 and Auxiliary Power Connector Diode.
(Volume 5, WP 0800, Figure 78)
V7
Start Aid Diode
Connector V7 and Start Aid Diode. (Volume 5, WP 0800, Figure
79)
V8
Pilot Shutoff Diode
Connector V8 and Pilot Shutoff Diode. (Volume 5, WP 0800,
Figure 80)
3.
Remove four screws (Figure 2, Item 7) and washers (Figure 2, Item 8) from bracket (Figure 2, Item 9), bracket
(Figure 2, Item 10), and frame (Figure 2, Item 11).
