TM 5-3805-294-23-4
FIELD MAINTENANCE
MONITOR WARNING ALARM REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition (cont.)
Tool Kit, General Mechanic's: Automotive (Volume
Negative battery cable disconnected. (WP 0521)
5, WP 0796, Table 2, Item 119)
Cab rear tray removed. (WP 0566)
Materials/Parts
Time to Complete
Tie Wraps (Volume 5, WP 0797, Table 1, Item
1.5 Hour(s)
56)
Lockwasher (Volume 5, WP 0798, Table 1, Item
56) Qty: 1
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 83 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Note position of each tie wrap and remove as required.
1.
Disconnect monitor warning alarm connector H3 (Figure 1, Item 1) from cab wiring harness W1 connector H3
(Figure 1, Item 2).
0520-1
