Figure 5. Hose Installation to Machine

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
373

TM 5-3805-294-23-4

0536

INSTALLATION - Continued

HYEX02903

Figure 5. Hose Installation to Machine.

WARNING

LUBRICATING OIL

Lightly lubricate O-ring (Figure 6, Item 23) with clean refrigerant oil.

0536-6
