TM 5-3805-294-23-4
FIELD MAINTENANCE
AIR CONDITIONER RECEIVER-DRYER REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Air conditioner system refrigerant recovered.
Tool Kit, Refrigeration
(Volume 5, WP 0796, Table 2, Item 120)
Negative battery cable disconnected. (WP 0521)
Materials/Parts
Lubricating Oil, Refrigerant Compressor (Volume
Time to Complete
5, WP 0797, Table 1, Item 27)
2.2 Hour(s)
O-ring (Volume 5, WP 0798, Table 1, Item 60)
Qty: 1
O-ring (Volume 5, WP 0798, Table 1, Item 61)
Qty: 1
Personnel Required
Utilities Equipment Repairer 91C (1)
References
TM 5-3805-294-24P: Fig. 123, Fig. 124, Fig. 125
(Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Remove bolt (Figure 1, Item 1), washer (Figure 1, Item 2), hose (Figure 1, Item 3), and O-ring (Figure 1, Item
4) from receiver-dryer (Figure 1, Item 5).
0538-1
