TM 5-3805-294-23-4
0556
INSTALLATION - Continued
2.
With the aid of an assistant and a suitable lifting device, install cab door (Figure 4, Item 4) to cab upper hinge
(Figure 4, Item 7) with two bolts (Figure 4, Item 5) and lockwashers (Figure 4, Item 6).
4
7
6
5
4
3
2
1
HYEX01878
Figure 4.
Cab Door Installation.
3.
Install two bolts (Figure 4, Item 1) and lockwashers (Figure 4, Item 2) to cab lower hinge (Figure 4, Item 3) and
cab door (Figure 4, Item 4).
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
