TM 5-3805-294-23-4
0556
REMOVAL - Continued
9
8
4
HYEX01877
Figure 2.
Cab Door Bushing Removal.
END OF TASK
INSTALLATION
1.
Install bushing (Figure 3, Item 8) to retaining clips (Figure 3, Item 9) starting at top of cab door (Figure 3, Item
4) and working towards bottom.
9
8
4
HYEX01877
Figure 3.
Cab Door Bushing Installation.
WARNING
Cab door weighs approximately 80 lb (36.3 kg). Do not attempt to lift or move cab door without
the aid of an assistant and suitable lifting device. Failure to comply may result in injury or
death to personnel.
